Yaoneng Flame retardant electronic yellow glue 1603 product details

UL electronic yellow glue refers to the electronic glue with flame retardant effect after glue curing, because of the color of the glue is yellow, so the industry has been called UL glue or UL yellow glue, UL flame retardant yellow glue, electronic yellow glue and other names.

The main material of UL flame retardant yellow glue is neoprene rubber. In addition, it is a single component glue composed of flame retardant materials and environmental protection solvents. It belongs to the solvent volatile bonding glue.After curing, the product has excellent flame retardant performance, which can reach UL94V0 flame retardant grade. It has the characteristics of insulation, fixing, positioning, reinforcement, earthquake resistance, moistureproof, strong adhesion and so on, and has good toughness.The following will introduce the details of Yoneng flame-retardant electronic yellow glue 1603 model products.

I. [Product Features]

1. It is a kind of one-component adhesive composed of environmental protection resin, flame retardant material, rubber environmental protection solvent, etc. It is simple and convenient to operate, short positioning time, and high initial adhesive strength.

2. After curing, the product has excellent flame retardant performance, insulation, earthquake resistance, moistureproof, strong bonding force and good toughness.

3. It can bond, paste and position electronic products;Good adhesion to plastics, wire, wood, glass, metal, leather, rubber, electronic parts, electronic components, circuit boards, semiconductor devices, ceramics.

Two, [scope of application]

Yoneng 1603 electronic flame retardant yellow glue is suitable for the following products and range:

1, can be widely used in audio-visual appliances, TV, monitor, audio and other household appliances in the loose parts fixed.Bonding, positioning, filling, sealing, insulating and fixing of electronic industrial components, PCB circuit boards, wire coils and other components.Including hard to stick materials such as rubber, plastics, ceramics and so on.

2, widely used in metal, glass, ceramics, PCB, semiconductor devices, plastic and other objects bonding, sealing, fixing.

III. [Technical Indicators]

Name of index		Condition/Unit	Index value
Before solidify	Name/Model	/	Flame retardant cement 1603
	Brand/Origin	/	Yaoneng/Guangdong
	Appearance	Visual inspection	Yellow half flow
	Viscosity	25℃/mpa.s	4500
	Density	25℃,g/cm3	1.2
	Surface drying time	25℃/min	1~3
	Full drying time	25℃/h	24－48
After solidify	Solidify appearance	/	Yellow hard colloid
	Hardness	shore D	45－55
	Flame resistance	UL94	V0
	Operation temperature	℃	－40－130
	Shear strength	N/cm2	130
	Permittivity	60Hz	3.0
	Volume resistivity	Ω.㎝	2.0×1013
	Dielectric dissipation factor	60Hz	0.003
	Breakdown voltage	Kv/mm	20-25

▲Above mechanical and electrical properties of products were measured 72 hours after complete curing at 25℃ and relative temperature 55%.

IV. [Usage]

1, clean: clean the surface of the construction substrate dust, water, oil and other impurities, and keep dry.

2, sizing: can be directly squeezed on the construction parts (3kg/ barrel packaging, can first pour the glue into the nozzle plastic bottle, or directly pour the glue into the plastic bottle with the glue dispenser dispensing), then the components are bonded and fixed.25℃ for 2-3 hours positioning (can enter the next process), 24 hours after the maximum strength (according to the size of the area, temperature and other factors, curing time will change).

5. [Precautions]

1. Venting and personal protection should be strengthened in the production process. Open fire is strictly prohibited and fire sources and heat sources should be kept away.

2, handling light, packaging cover should be promptly covered, not used up glue should be sealed, so as not to glue thickening.

3, the test of various performance parameters should be carried out at least 72 hours after sizing, at this time the glue is completely cured.

4. For more data and information, please consult Shenzhen Yaoneng Company for relevant advice and help.
